Our solutions

Revtech solutions are unique and no similar system can be found in the world. Our innovative system allows continuous heating to treat dry ingredients for both the food and the chemical industry.
The heart of our technology lies on an ingenious combination of electrical heat generation and vibrational transport techniques in a closed stainless-steel spiral, allowing rapid and highly efficient heating to take place.
What sets our treatment process apart is its capability to operate within a controlled atmosphere, facilitating the direct introduction of steam, hot air, or any desired gases in direct contact with your product. This ensures precise and effective treatment tailored to your specific needs.

How does it work?

Revtech continuous electric thermal treatment line with five numbered steps: 1 product feeding, 2 vibratory conveying from bottom to top along a stainless-steel spiral, 3 electrical heating under controlled atmosphere, 4 cooling with filtered air, 5 discharge, ready to pack or further process.
  1. FeedingThe product is fed continuously into the system.
  2. ConveyingThe product moves smoothly from bottom to top along a closed stainless-steel spiral, driven by gentle vibration, as a thin, even layer.
  3. Heating under controlled atmosphereThe spiral is heated electrically, zone by zone, and transfers heat to the product by direct contact. Steam, hot air or inert gas is injected into the product flow, then extracted on the opposite side.
  4. CoolingThe product is cooled with filtered air down to the target temperature, which helps prevent recontamination after treatment.
  5. Ready to pack or further processThe treated product leaves the line continuously, ready for packaging or the next processing step.

Adjustable parameters

Every Revtech system is custom-built around your product and process requirements. Each parameter below is set to match your goals.

Product

Our system can handle a wide range of sizes, densities, and moisture levels—from fine powders to larger particles.

Temperature

From ambient up to 300 °C for food applications and up to 700 °C for chemical processes, with a control accuracy of ±1 °C. The tower can be divided into independent heating zones, each set at its own temperature.

Flowrate

Throughput is set by the spiral diameter, from 100 kg/h to 6 t/h per unit. Higher capacities are reached with units operating in parallel.

Residence time

Residence time is adjusted through the vibration motor settings. The system operates close to plug flow, so every particle receives the same thermal treatment.

Controlled Atmosphere

Openings on each side of the tower allow steam, hot air, N₂, CO₂ or other gases to be injected in direct contact with the product. The gas is then extracted on the opposite side.

Key Applications

From food to chemical processing, our technology supports a wide variety of applications. Discover six of them in more detail through our dedicated solution pages.

Have another application in mind? Let’s explore what’s possible together. Contact us to discuss your project.

Benefits

Discover how Revtech’s continuous thermal processing technology helps manufacturers improve process control, operational efficiency and industrial reliability.

Process & product quality

Industrial process control icon featuring adjustable settings on a monitor and a gear, symbolizing precise control of processing parameters in Revtech technology.

Precise Process Control

Our technology provides precise control over key processing parameters, enabling manufacturers to tailor treatment conditions to the specific requirements of each product and application. This flexibility supports consistent, reliable processing across a wide range of industrial uses.

Uniform, repeatable treatment

A plug-flow design with no dead zones ensures uniform treatment throughout the process. Simply select the same recipe to reproduce consistent processing conditions, batch after batch, day after day.

One technology many applications

From food to chemical processing, our versatile technology adapts to a wide range of products and applications. Different processes, one flexible solution.

Operations

Seamless integration in your production line

Designed for continuous operation, our technology fits naturally into industrial production lines. Simply feed the product in and collect it at the outlet, with minimal operator intervention. By eliminating repeated loading and unloading cycles, continuous processing streamlines production, supports industrial-scale throughput and helps reduce operating costs.

24/7 operations, low maintenance

Built for continuous industrial operation, our equipment is designed to run reliably around the clock. Yet, starting up and shutting down is quick and straightforward, offering flexibility when production schedules change. With minimal maintenance requirements, our technology helps reduce downtime and operating costs — a benefit consistently highlighted by our customers.

Compact footprint

Our equipment is designed to fit your factory, not the other way around. With a compact footprint and a flexible layout, we can adapt the machine design and the positioning of line components to accommodate existing buildings and production constraints. Compared with conventional conveyor-based processing systems, our technology requires significantly less floor space, helping you make the most of every valuable square metre.

Sustainability & reliability

100% Electric, Lower Carbon Footprint

Powered entirely by electricity, our technology offers a cleaner alternative to conventional fossil-fuel-based thermal processing. By eliminating on-site combustion, it helps manufacturers reduce their dependence on fossil fuels and supports their transition towards more sustainable production.

Illustration of France with a factory located in the Drôme region and a handshake symbolizing trusted local manufacturing partners.

Built in France, Backed by Trusted Partners

Revtech equipment is assembled at our facility in France, in close collaboration with a network of trusted, long-standing local partners. These established relationships help us maintain control over manufacturing quality, ensure reliable sourcing and deliver equipment built to demanding industrial standards.

Designed for Long-Term Reliability

Industrial equipment is a long-term investment. Our technology is designed with durability and reliability in mind, combining robust construction with a straightforward mechanical design to support dependable performance throughout its service life.

What engineering and procurement teams ask us most often

Each system is sized from your process data: target throughput, product characteristics (bulk density, particle size, moisture) and the residence time required by the treatment. These determine the dimensions of the spiral and the heating power.
A single unit covers from 100 kg/h to 6,000 kg/h. Beyond that, several units run in parallel. Our largest installation to date has been validated at 14 t/h.
Contact us with your process data to size your installation.

Very little. Unlike conventional horizontal systems such as belt or tunnel equipment, our vertical spiral design concentrates the entire treatment path in a compact tower. Depending on throughput, a system stands 3 to 11 m high, with a footprint from 3 × 3 m to 10 × 10 m.
This is a real advantage when floor space is limited: our systems are often shoehorned into tight spaces where a horizontal line would never fit. And because every installation is tailor-made, not a catalog product, we adapt its design to the available space in your building.
Contact us to study the integration into your plant.

Our systems run 100% on electricity, with no combustion on site. Heat is generated directly in the spiral and transferred to the product as it moves, which keeps losses low.
As a reference, a steam pasteurization line at 1 t/h typically consumes around 100 kWh per hour of operation. For other applications, consumption depends on the target temperature, the product and the residence time, so we calculate it case by case.
Electric heating also lets you cut the direct CO₂ emissions of your thermal process, especially where the grid relies on low-carbon power.
Contact us for an estimate based on your process.



Every installation is tailor-made, so there is no catalog price. The investment mainly depends on:

  • the required throughput and the number of units,
  • the application and the process conditions (temperature, atmosphere, residence time),
  • the materials of construction and the hygienic requirements,
  • the level of automation and the peripheral equipment (feeding, cooling, steam generation…),
  • the installation and commissioning scope.

Beyond the initial investment, our systems are designed for a low total cost of ownership: continuous operation, 100% electric heating and limited maintenance.
Contact us with your project details to receive a tailored quote.

  • Electricity: our systems adapt to your local voltage and frequency. The required installed power (kVA) depends on throughput, process temperature and application, and is calculated case by case.
  • Steam (for steam-based treatments such as pasteurization): either we supply a Revtech steam generator, which only needs a softened water supply, or we connect to your existing culinary steam network if one is available.
  • Compressed air: a limited supply is needed.
  • Water: only if you opt for wet cleaning.

Each system is designed and manufactured in our factory in France, with long-standing local suppliers. Controlling the entire chain, from design to assembly, keeps lead times reliable. They typically range from 5 to 9 months after order confirmation, depending on the size and complexity of the project and on our production schedule.
Contact us to plan your project timeline.

Our systems are equipped with remote access, so our team can connect to your installation, see what is happening and help with diagnosis, without waiting for a site visit.
A dedicated after-sales team of three experienced specialists supports you throughout the life of your installation. When needed, our technicians travel on site wherever our systems are installed to provide hands-on assistance.
